AW00089317000 Specifications, Requirements, and Precautions
Basler ace GigE 15
Camera Power
Requirements
PoE (Power over Ethernet 802.3af compliant)
or
+12 VDC (±10%), < 1% ripple, supplied via the camera’s 6-pin Hirose connector;
Cable must be at least a 26 AWG cable. Max. cable length: 10 m
~ 2.8 W when using Power over Ethernet
~ 2.5 W @ 12 VDC when supplied via the camera’s 6-pin
connector
~ 2.9 W when using Power
over Ethernet
~ 2.6 W @ 12 VDC when
supplied via the camera’s 6-
pin connector
I/O Ports 1 opto-isolated input line and 1 opto-isolated output line
Lens Adapter C-mount
Size (L x W x H) 42.0 mm x 29 mm x 29 mm (without lens adapter or connectors)
60.3 mm x 29 mm x 29 mm (with lens adapter and connectors)
Weight < 90 g
Conformity CE (*), UL, FCC, GenICam, GigE Vision, IP30, RoHS, IEEE 802.3af (PoE)
* The CE Conformity Declaration is available on the Basler website:
www.baslerweb.com
Software Basler pylon 4 Camera Software Suite:
Available for Windows in 32- and 64-bit versions.
Basler pylon 3.2.x:
Available for Windows or Linux in 32- and 64-bit versions.
Specification acA2000-50gm/gc -
CMV2000-V3
acA2000-50gmNIR -
CMV2000-V3
acA2040-25gm/gc -
CMV4000-V3
Table 7: General Specifications (acA2000-50gm/gc - CMV2000-V3, acA2000-50gmNIR - CMV2000-V3, acA2040-
25gm/gc - CMV4000-V3)
