Specifications, Requirements, and Precautions AW00089317000
16 Basler ace GigE
Specification acA2040-25gmNIR acA2040-25gmNIR -
CMV4000-V3
acA2500-14gm/gc
Sensor Size
(H x V pixels)
2048 x 2048 gm: 2592 x 1944
gc: 2590 x 1942
Sensor Type CMOSIS CMV4000-2E12M
Progressive scan CMOS
Global shutter
CMOSIS CMV4000-
3E12M
Progressive scan CMOS
Global shutter
Aptina MT9P031
Progressive scan CMOS
Rolling shutter
Optical Size 1" 1/2.5"
Pixel Size 5.5 µm x 5.5 µm 2.2 µm x 2.2 µm
Max. Frame Rate
(at full resolution)
25 fps 14.6 fps
Mono/Color Mono (NIR) Mono or color (color models
include a Bayer pattern RGB
filter on the sensor)
Data Output Type Fast Ethernet (100 Mbit/s) or Gigabit Ethernet (1000 Mbit/s)
Pixel Data Formats Mono and Mono (NIR) Models:
Mono 8 YUV 4:2:2 Packed
Mono 12 YUV 4:2:2 (YUYV) Packed
Mono 12 Packed
Color Models:
Mono 8
Bayer GR 8
Bayer GR 12
Bayer GR 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV) Packed
Color Models:
Mono 8
Bayer GB 8
Bayer GB 12
Bayer GB 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV) Packed
ADC Bit Depth 12 bits
Synchronization Via external trigger signal, via the Ethernet connection, or free run
Exposure Control Via external trigger signal or programmable via the camera API
Camera Power
Requirements
PoE (Power over Ethernet 802.3af compliant) or
+12 VDC (±10%), < 1% ripple, supplied via the camera’s 6-pin Hirose connector;
Cable must be at least a 26 AWG cable. Max. cable length: 10 m
~ 2.9 W when using Power over Ethernet
~ 2.6 W @ 12 VDC when supplied via the camera’s 6-pin
connector
~ 2.5 W when using Power
over Ethernet
~ 2.2 W @ 12 VDC when
supplied via the camera’s 6-
pin connector
I/O Ports 1 opto-isolated input line and 1 opto-isolated output line
Lens Adapter C-mount C-mount; CS-mount
Table 8: General Specifications (acA2040-25gmNIR, acA2040-25gmNIR - CMV40000-V3, acA2500-14gm/gc)
