Standard Features AW00089317000
258 Basler ace GigE
With horizontal binning, adjacent pixels from 2 columns, 3 columns, or a maximum of 4 columns are
summed and are reported out of the camera as a single pixel. Figure 104 illustrates horizontal
binning.
You can combine vertical and horizontal binning. This, however, may cause objects to appear
distorted in the image. For more information about possible image distortion due to combined
vertical and horizontal binning, see Section 10.9.3 on page 261.
acA1280-60gm, acA1300-60gm, and acA1600-60gm
For each binning method (horizontal and vertical binning) you can determine
whether you want to use the summing method or the averaging method to be
applied.
Horizontal Binning by 2 Horizontal Binning by 3 Horizontal Binning by 4
Fig. 104: Horizontal Binning on Monochrome Cameras
