Description
7990044_030_10 – 2078511 – 2023-01-19 39
3.10.2 Operating tabletop with head section and universal section
Version 1
1. A head section is [A] attached at the head end of the
operating tabletop.
2. The universal section [B] is attached at the foot end of the
operating tabletop.
3. Normal patient orientation is active on the operating table.
Version 2
1. No tabletop section is required at the head end of the
operating tabletop.
2. The universal section [A] and a head section [B] are attached
at the foot end of the operating tabletop.
3. The patient orientation on the operating table is switched to
inverted.
3.10.3 Operating tabletop with head section, seat section extension and leg sections
1. A head section is [A] attached at the head end of the
operating tabletop.
2. A seat section extension [B] and a leg section are [C] attached
at the foot end of the operating tabletop.
3. The orientation of the patient on the operating tabletop is
normal.
Permissible load:
450 kg /
992 lbs
Patient weights of up to 450 kg / 992 lbs are
permitted when the operating tabletop's longitudinal
slide is in the level position.
225 kg /
496 lbs
Patient weights of up to 225 kg / 496 lbs are possible
without any restrictions applying to the operating
table functions.
Attention: Additional accessories on the operating table reduce
the permissible patient weight.
Permissible load on the operating tabletop:
200 kg /
440 lbs
Patient weights of up to 200 kg / 440 lbs are possible
without any restrictions applying to the operating
table functions. Attention: Additional accessories on
the operating table reduce the permissible patient
weight.
Permissible load:
225 kg /
496 lbs
Patient weights of up to 225 kg / 496 lbs are possible
without any restrictions applying to the operating
table functions. Note that additional accessory parts
reduce the permissible patient weight.
