Description
7990044_030_10 – 2078511 – 2023-01-19 45
3.11.3 Operating tabletop with head section, upper back section and leg section
1. An upper back section [A] and a head section [B] are attached
at the head end of the operating tabletop.
2. A leg section is [C] attached to the foot end of the operating
tabletop.
3. The orientation of the patient on the operating tabletop is
normal.
3.11.4 Operating tabletop with head section, seat section extension and leg sections
1. A head section is [A] attached at the head end of the
operating tabletop.
2. A seat section extension [B] and a leg section are [C] attached
at the foot end of the operating tabletop. The permissible
patient weight depends on the leg section used.
3. The orientation of the patient on the operating tabletop is
normal.
Permissible load:
450 kg /
992 lbs
Patient weights of up to 450 kg / 992 lbs are
permitted under the following conditions:
1. The longitudinal slide adjustment of the
operating tabletop must be in level position.
2. The operating table column can be inclined up to
15° about the transverse axis (tilt). Tilt
automatically stops at 15° which is indicated
acoustically by means of a signal tone. Do not
continue to tilt the operating table column after
the intermediate stop is reached.
250 kg /
551 lbs
Patient weights of up to 250 kg / 551 lbs are possible
without any restrictions applying to the operating
table functions.
Note that additional accessory parts reduce the permissible
patient weight.
Permissible load:
225 kg /
496 lbs
Patient weights of up to 225 kg / 496 lbs are
permitted, provided that no four-part leg section is
attached to the operating tabletop. The operating
table functions can be used without limitation.
200 kg /
440 lbs
Patient weights of up to 200 kg / 440 lbs are possible
with any leg section. The operating table functions
can be used without limitation.
Note that additional accessory parts reduce the permissible
patient weight.
