baxter TruSystem 7000 User Manual

Description
40
7990044_030_10 – 2078511 – 2023-01-19
3.10.4 Operating tabletop with seat section extension, upper back section and head section
1. No tabletop section is required at the head end of the
operating tabletop.
2. A seat section extension [A], an upper back section [B] and a
head section are [C] attached at the foot end of the operating
tabletop.
3. The orientation of the patient on the operating tabletop is
inverted.
3.10.5 Operating tabletop with Carbon 600 / narrow Carbon 600 tabletop section
1. No tabletop section is required at the head end of the
operating tabletop.
2. A Carbon 600 [A] / Carbon 600 narrow tabletop section with
X-RAY [B] head-positioning accessory is fastened to the foot
end of the operating tabletop.
3. The orientation of the patient on the operating tabletop is
inverted.
C
A
B
Permissible load:
225 kg /
496 lbs
Patient weights of up to 225 kg / 496 lbs are possible
with restricted longitudinal slide toward the head end
of the patient.
160 kg /
352 lbs
Patient weights of up to 160 kg / 352 lbs are possible
without any restrictions applying to the operating
table functions.
Note that additional accessory parts reduce the permissible
patient weight.
A
B
Permissible load:
160 kg /
352 lbs
Operating tabletop with Carbon 600 tabletop
section:
Patient weights of up to 160 kg / 352 lbs are possible
with restricted longitudinal slide toward the head end
of the patient.
Operating tabletop with Carbon 600 narrow
tabletop section:
Patient weights of up to 160 kg / 352 lbs are possible
without any restrictions applying to the operating
table functions.
Note that additional accessory parts reduce the permissible
patient weight.
