Use
7990044_030_10 – 2078511 – 2023-01-19 65
Restrictions:
Longitudinal travel is automatically restricted or locked in the
following situations.
1. The longitudinal travel is locked once the extension adapter
is hooked onto the operating tabletop. The presence sensor
is active.
2. The longitudinal travel may be limited if the leg section joints
or lower back section joints are inclined downward. The
setting range for longitudinal travel depends on the angles of
inclination of the joints. If a larger setting range is required,
the joints must be moved upward.
3. Longitudinal travel may be restricted if the operating
tabletop is steeply inclined. If a larger adjustment range is
required, the inclination of the operating tabletop must be
reduced.
4. Longitudinal travel is restricted if a long tabletop section is
hooked onto the leg section joints (e.g. Carbon 1200 tabletop
segment). You will hear an error message if longitudinal travel
is in the impermissible range. In this case, only longitudinal
travel toward the head end is possible until the permissible
range is reached. Furthermore, the inclination of the
operating tabletop (tilting, Trendelenburg) can only move
towards the level position and the lift function is locked.
4.10.6 Back section / back section joints
Back section up:
Press the [i14] key on the remote control or column keypad.
Back section down:
Press the [i15] key on the remote control or column keypad.
Restrictions:
The setting range of the joints is automatically restricted or
blocked in the following situations.
1. Depending on the longitudinal travel, the downwards setting
range of the joints may be restricted. If a larger setting range
is required, the longitudinal travel needs to be changed.
2. The setting ranges for the normal and inverted patient
positions are different (see Chapter 10).
