Use
66
7990044_030_10 – 2078511 – 2023-01-19
4.10.7 Leg section joints together
There are side rails on the leg section joints of the operating table
(not an option for the U-version of the operating table). When
adjusting the leg section joints, accessories connected to the side
rail are thus also repositioned.
Arrange the accessory on the operating table in such a manner
that it does not collide with another accessories, tabletop sections
or the operating table during positioning.
If the joints are in different positions, the function automatically
stops once the first joint reaches the level position or end position.
Leg section up:
Press the [i12] key on the remote control or column keypad.
Leg section down:
Press the [i13] key on the remote control or column keypad.
Restrictions:
The setting range of the joints is automatically restricted or
blocked in the following situations.
1. Depending on the longitudinal travel, the downwards setting
range of the joints may be restricted. If a larger setting range
is required, the longitudinal travel needs to be changed.
2. The setting ranges for the normal and inverted patient
positions are different (see Chapter 10).
3. The leg section joints are locked once the extension adapter
is hooked onto the operating tabletop.
4.10.8 Leg section joints individually
There are side rails on the leg section joints of the operating table
(not an option for the U-version of the operating table). When
adjusting the leg section joints, accessories connected to the side
rail are thus also repositioned.
The function can only be selected with the remote control.
1. Remove an accessory part if it is attached to two joints
simultaneously (e.g., a colonoscopy roller).
2. Arrange the accessory on the operating table in such a
manner that it does not collide with another accessories,
tabletop sections or the operating table during positioning.
Set the spreadable leg sections so that they are not on top of
one another.
