Description
42
7990044_030_10 – 2078511 – 2023-01-19
3.10.9 Operating tabletop with pediatric extension section
1. No tabletop section is required at the head end of the
operating tabletop.
2. The pediatric extension section [A] is attached at the foot end
of the operating tabletop.
3. The patient orientation on the operating table is switched to
inverted.
3.10.10 Operating tabletop with ophthalmological adapter and leg sections
1. The ophthalmological adapter [A] is attached at the head end
of the operating tabletop.
Accessories for head positioning can be attached to the
ophthalmological adapter.
2. Leg sections [B] are attached at the foot end of the operating
tabletop.
3. Normal patient orientation is active on the operating table.
3.10.11 Operating tabletop with seat section extension and ophthalmological adapter
1. No tabletop section is required at the head end of the
operating tabletop.
2. The seat section extension [A] with the ophthalmological
adapter [B] is attached at the foot end of the operating
tabletop.
Accessories for head positioning can be attached to the
ophthalmological adapter.
3. The patient orientation on the operating table is switched to
inverted.
Permissible load:
40 kg /
88 lbs
A patient weight of up to 40 kg / 88 lbs is permitted.
Attention: Additional accessories on the operating table reduce
the permissible patient weight.
Permissible load:
200 kg /
440 lbs
Patient weights of up to 200 kg / 440 lbs are
permitted if the load capacity of head positioning
device on the ophthalmological adapter is observed.
Attention: Additional accessories on the operating table reduce
the permissible patient weight.
Permissible load:
225 kg /
496 lbs
Patient weights of up to 225 kg / 496 lbs are
permitted if the longitudinal extension on the head
positioning device is pushed in.
Attention: Additional accessories on the operating table reduce
the permissible patient weight.
