Use
7990044_030_10 – 2078511 – 2023-01-19 63
4.10.2 Lift
Risk to patients due to collision
Risk of crushing for the user
When lowering the operating tabletop, collisions may occur with
the running gear, the floor, furnishings or devices located below
the operating tabletop.
• Clear the area beneath the table top or raise the corresponding
tabletop sections (leg/back section joints). Next, continue
moving the operating tabletop downward.
• Pay particular attention to leg sections that are lowered.
Raise:
Press the [i5] key on the remote control or column keypad.
Lower:
Press the [i6] key on the remote control or column keypad.
4.10.3 Tilt
For safety reasons, the tilt function automatically stops at
maximum 15° (see Chapter 3.19).
Tilt left:
Press the [i9] key on the remote control or column keypad.
Tilt right:
Press the [i10] key on the remote control or column keypad.
Restrictions:
The tilt adjustment range is also limited for a severe reverse
Trendelenburg/Trendelenburg position. If a larger adjustment
range is required for the tilt, the reverse Trendelenburg/
Trendelenburg position of the operating tabletop must be
reduced.
