baxter TruSystem 7000 User Manual

Description
7990044_030_10 – 2078511 – 2023-01-19 41
3.10.6 Operating tabletop with Carbon 1200 tabletop section
1. No tabletop section may be attached to the head end of the
operating tabletop.
2. A Carbon 1200 tabletop section is [A] attached at the foot end
of the operating tabletop.
3. The orientation of the patient on the operating tabletop is
normal or inverted. The permissible patient weight depends
on the patient position.
3.10.7 Operating tabletop with extension unit
1. The extension unit [A] is attached at the foot end of the
operating tabletop.
2. The orientation of the patient on the operating tabletop is
normal.
3.10.8 Operating tabletop with shoulder chair
1. No tabletop section is required at the head end of the
operating tabletop.
2. The shoulder chair [A] with the head-positioning accessory
[B] is fastened to the foot end of the operating tabletop.
3. The orientation of the patient on the operating tabletop is
inverted.
A
Permissible load:
160 kg /
352 lbs
A patient weight of up to 160 kg / 352 lbs in the
normal patient position is possible with restriction of
the operating table functions.
135 kg /
297 lbs
A patient weight of up to 135 kg / 297 lbs in the
inverse patient position is possible with restriction of
the operating table functions.
Note that additional accessory parts reduce the permissible
patient weight.
A
Permissible load:
160 kg /
352 lbs
Patient weights of up to 160 kg / 352 lbs are possible
without any restrictions applying to the operating
table functions.
A
B
Permissible load:
225 kg /
496 lbs
A patient weight of up to 225 kg / 496 lbs is
permitted.
Note that additional accessory parts reduce the permissible
patient weight.
