Use
7990044_030_10 – 2078511 – 2023-01-19 71
4.15 Running gear assistance (directional travel, turning the operating table)
Running gear assistance supports directional movement or the
turning of the operating table on the spot. Transverse travel of the
operating table is not possible.
Risk of personal injury due to crushing
• Do not allow the feet to get caught in the running gear recess
when turning or moving the operating table. Note the crush
hazard symbol on the running gear!
1. Prepare the operating table according to the requirements
on page 68 if it is in the jacked-up position.
2. Press key [i54] until an audible signal sounds.
The signal will sound intermittently until the additional wheel
[17] in the middle under the running gear is extended. The
indicator next to key [i54] on the column keypad lights up.
3. The operating table can be turned on the spot or driven at
will.
4.16 Traction drive (operating table version MB/MBW)
The operating table traction drive, variant MB/MBW, is located on
the additional wheel in the center under the running gear. It assists
the user when moving the operating table, particularly with heavy
patients. For safety reasons, the traction drive can only be
controlled using the wired remote control. The speed of the
traction drive can be set individually (see Chapter 3.19).
Hazard to the patient
• Monitoring and controlling the driving movement of the
operating table. A defect or malfunction in the running gear
electronics can result in brake support failure. If necessary,
apply the operating table brakes manually (by hand).
