baxter TruSystem 7000 - Trendelenburg; Longitudinal Slide

Use
64
7990044_030_10 – 2078511 – 2023-01-19
4.10.4 Trendelenburg
CAUTION
Risk to patients due to collision
Risk of crushing for the user
When tilting the operating tabletop, collisions may occur with the
column, the floor, the furnishings or the devices beneath the
tabletop that may be covered by draping or underlays.
• Monitor all movements on the operating table up to the end
position and stop the function if a dangerous situation arises.
• Clear the area beneath the operating tabletop, move the
tabletop to a higher lift position or raise the corresponding
tabletop sections (leg/back section joints). Then continue to
the Trendelenburg/reverse Trendelenburg position.
Trendelenburg:
Press the [i7] key on the remote control or column keypad.
Reverse Trendelenburg:
Press the [i8] key on the remote control or column keypad.
Restrictions:
The reverse Trendelenburg/Trendelenburg position range is also
limited for a severe tilt position. If a larger adjustment range is
required for the reverse Trendelenburg/Trendelenburg position,
the tilt of the operating tabletop must be reduced.
4.10.5 Longitudinal slide
CAUTION
Risk to patients due to collisions
Risk of crushing for the user
Accessory parts on the side rail may collide with the operating
table column during longitudinal travel.
• Monitor all motorized movements on the operating table up to
the end position and stop the function before a dangerous
situation arises.
Longitudinal slide, head end:
Press the [i16] key on the remote control or column keypad.
Longitudinal slide, foot end:
Press the [i17] key on the remote control or column keypad.
