Technical data
86
7990044_030_10 – 2078511 – 2023-01-19
10 Technical data
10.1 Operating table
Dimensions
Length of the operating tabletop (from
one hook coupling to the next)
Operating table with two-part operating
tabletop:
1248 mm / 49.13 inch [A]
Operating table with one-part operating
tabletop:
843 mm / 33.19 inch [B]
Width [C] of the operating tabletop with
side rails according to European standard
601 mm / 23.66 inch
Width [C] with side rails according to
United States standard
600 mm / 23.62 inch
Width [C] with side rails according to
Japanese standard
599 mm / 23.58 inch
Height [D] of the operating table (without
pads)
59 cm to 114 cm (tolerance ±1 cm) /
23.23 inch to 44.88 inch
(tolerance ±0.39 inch)
Column protection (length x width x
height)
(403 x 452 x 60) mm /
(15.87 x 17.80 x 2.36) inch
Weight/load
Dead weight of operating table with two-
piece operating tabletop
– Operating table with power drive unit
(MB/MBW): 244 kg / 538 lbs
– Operating table without power drive
unit: 240 kg / 529 lbs
Dead weight of operating table with one-
piece operating tabletop
227 kg / 500 lbs
Dead weight of the column cladding
protection
2.5 kg / 5.5 lbs
Maximum operating table load 450 kg / 992 lbs (depending on the
operating table equipment and the patient
weight)
