Troubleshooting
7990044_030_10 – 2078511 – 2023-01-19 83
Operating table cannot be
charged, the battery status
indicator flashes
The operating table or the
battery is defective
Contact Technical Customer
Service
(Reverse) Trendelenburg position
cannot be fully attained
The tilt angle setting is too high Reduce the tilt
Tilt position cannot be fully
attained
The (reverse) Trendelenburg
angle setting is too high
Reduce the (reverse)
Trendelenburg setting
Tilt cannot be adjusted when the
operating table is unlocked (no
brakes applied).
OK - for safety reasons only the
functions for driving mode are
active, all other operating table
functions are locked
Lock operating table
Operating table cannot be
unlocked
Tilt not in horizontal position (<
10°) and/or
Set tilt to horizontal
the longitudinal travel is not in
level position and/or
Set the longitudinal travel to the
level position
Lift has not been lowered far
enough
Lower the tabletop until the label
on the column cladding is fully
hidden
The operating table drive mode
does not operate with wired
remote control
Power cable connected to the
operating table
Disconnect the operating table
from the line power
Leg sections cannot be adjusted
far enough down
Longitudinal travel too far toward
the head end
Adjust longitudinal travel toward
the foot end
Back section cannot be adjusted
far enough down
Longitudinal travel too far toward
the foot end
Adjust longitudinal travel toward
the head end
Audible signal when moving the
tabletop
Sensor error Contact Technical Customer
Service
Audible signal while leveling if the
leg sections are approaching one
another
Possible risk of collision (signal is
warning)
OK (not an error)
Error Possible cause Correction
