Belanger CUBE - Specifications

Cube
®
Installation & Startup
1MANUL963 Belanger, Inc. * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 16-1
PURCLEAN
™
SPOT FREE RINSE SYSTEM
Water Stabilizer (replaces softener)
Inlet & Pressure Pump
Carbon Tank with Auto Back Flushing Head
Multi-Stage Pressure Pump
Low Pressure Shut Off
Automatic Membrane Flush
Production & Reject Meters
On Board TDS Meter
Aluminum Frame
Repressurization and / or Reject Recapture Pump
Thin Film Membrane
Hinged Control Box - Quick and Easy Internal Access
ETL Listed
Chapter 16 Spot Free Rinse (RO) Option
Specifications
Specifications
Water Requirements
(2) 1” Water line w/FPT ball valves, 20GPM at 30PSI. Mount 4 feet up from floor to the right of the
spot free rinse system and (1) drain.
Electrical
Requirements
1Ph
(1) 220V 20 Amp single phase circuit with its own L6-20 locking receptacle.
Put plug 5 feet up from the floor to the right of the spot free rinse system.
3Ph
(1) 208/230 or 460/480 20-amp circuit, put circuit 5 feet up from the floor to the
right of the spot-free rinse system.
RO Output
Production - 1.6 GPM
Reject
1.7 GPM
RO Motor
1 HP Booster pump
RO Motor Amps
1Ph 208/230 = 10.25 amps
3Ph 208/230 = 5.5 amps
3Ph 460/480 = 3.25 amps
Dimensions
30” wide x 44” tall x 12” deep
Net Weight
350 lbs.
Delivery Pump
Standard delivery pump 15 GPM max at 50 PSI max. Automatic freshwater bypass pressure and
GPM varies depending on which car wash application (call PurClean for more info).
