Chapter 16 Spot Free Rinse (RO) Option
Utility Requirements and Dimensions
CUSTOMER UTILITY REQUIREMENTS
TABLE 1
DIMENSIONS
TABLE 2
Please ensure that you leave enough room around the equipment to
allow technicians clearance to service the machines.
PRODUCTION
WATER LINE
POWER REQ
UNIT SIZE GPD
SIZE/ PSI / GPM
VOLTS / AMPS / PH
1,000
1” / 30 / 20
110v / 20 / 1
2,000
1” / 30 / 20
220v / 20 / 1
3,000
1” / 30 / 20
220v / 20 / 1
4,500
1” / 30 / 20
220v / 20 / 1
6,000
1” / 40 / 30
220v / 20 / 1
8,000
1” / 40 / 30
220v / 20 / 1
10,000
1” / 40 / 30
220v / 20 / 1
15,000
1 1/2” / 40 / 40
220v / 30 / 3
MODEL
H
W
D
PC 1000 WM
36”
29”
11”
PC 2000 WM
44”
29”
11”
PC 3000 WM
44”
29”
11”
PC 4500 WM
44”
36”
11”
PC 3000 STM
75”
36”
24”
PC 4500 STM
75”
36”
24”
PC 6000 STM
77”
36”
24”
PC 8000 STM
96”
36”
24”
PC 10,000 STM
96”
36”
24”
PC 15,000 STM
94”
39”
25”
