Chapter 4 Electrical Overview and Panels
Cube® HMI Panel
The operator interface should be mounted an area out of direct sun light. This panel is sealed
against water intrusion, which means it does not breathe very well.
We recommend mounting this unit within sight of the entire wash but away from exposure to
water. The Exit end of the wash is a safe zone although that location makes it difficult to
manually load vehicles from the operator interface. The best-case scenario would be to mount
it behind glass at the entrance of the bay.
NOTE TO ELECTRICIANS AND ARCHITECTS
The communication cable for the Cube® HMI Panel is a CAT-5E.
The above image reflects the Cube® HMI (Human Machine Interface) Panel Home Screen
REFER TO YOUR SUPPLIED ELECTRICAL PRINTS, AND
SITE-SPECIFIC DRAWINGS FOR INSTALLATION DETAILS
