Chapter 4 Electrical Overview and Panels
Electrical Standards Overview
Utility Requirements
See Local Codes and Manufacturer Labels for wiring and branch circuit protection sizes.
Note: See the Conduit Electrical information page of the system print set for full details.
All the electrical wires, conduit, and conduit fittings for the electrical connections to the Building
Panel and HMI Panel are to be field supplied. The electrical cables from the CAT Track Cable
Carrier are to be routed and connected to the Carriage Panel; any conduit of conduit fittings for
these cables are to be field supplied.
The electrical cables from the Cable Carrier are 42 feet in length, if the Carriage Panel is further
than 42’, the cables will need to be extended. In this case, a Junction Box and additional cable
can be ordered through the Belanger® Aftermarket group, reference the part numbers in the
chart below and specify the length per foot needed of each cable.
Part Number
Qty.
Description
112216
1
Cube® Junction Box
1ELECT-CB840
TBD
Used to extend the Sudzer® Cable
1ELECT-CB846
TBD
Used to extend all 7 Drive Cables
1ELECT-CB865
TBD
Used to extend the Pneumatic Manifold Feed
1ELECT-CB869
TBD
Used to extend the LED Feed
1ELECT-CB550
TBD
Used to extend the cable for the Sensor Block
ITEM
Typical
Breaker
Electrical
Water
Description
AMPS
Volts
Phase
Size
GPM
PSI
Carriage Panel
40
208-240
3
3/4"
Building Panel (High Pressure)
50
208-240
3
1”
20
120
1
1/2"
Building Panel (Reg. Pressure)
20
208-240
3
3/4"
20
120
1
1/2"
Spot Free (RO)
*Sold Separately
20 x 2
220
1 (2 feeds
at 20AMP)
1”
20
30
Undercarriage Options
Building Panel Controlled
3/4"
12
40
Bug Spray Applicator
Building Panel Controlled
3/4"
12
40
Air Cannon™ Dryer
See supplied Air Cannon™ Dryer manual
AirBlade® Dryer
See supplied AirBlade® Dryer manual
Air Compressor
*Sold Separately
20
208-240
3
6
SCFM
110
