4-34
The difference is within ±3 mm when 0, 50 or 200 mmHg is set for NIBP
accuracy test.
There is no leakage with NIBP, or the manual leakage test result does not
exceed 6mmHg/min.
Temp test
The value displayed for each Temp channel of the monitor is within
37±0.1ºC.
IBP test
The static pressure value displayed for each IBP channel is within 200±2
mmHg.
The ART and LV waves for each IBP channel are displayed correctly.
C.O. test
The TB value displayed on the monitor is within 37±0.1ºC.
The displayed C.O. value is within 5±0.25 L/min.
Mainstream CO
2
test
The mainstream CO
2
is zeroed successfully and the waveform baseline
recovers to zero.
CO
2
Apnea alarm behaves correctly.
The displayed CO
2
value is 45±2 mmHg.
Sidestream CO
2
test
Block the gas inlet of the module or watertrap. The sidestream CO
2
flowrate is slower than 10ml/min and an alarm of CO2 Airway Occluded
is given. It indicates that there is no leakage.
The displayed CO
2
value is 6±0.05%.
The displayed O
2
value is within ±2% (when O2≤80%) or ±3%
(80%≤O2≤10
0%)
Microstream CO
2
test
Block the gas inlet of the module or watertrap for about 30 seconds. An
alarm of CO2 Airway Occluded is given. It indicates that there is no
leakage.
The displayed CO
2
value is 45±2 mmHg.
AG test
When AG flowrate is slower than 10ml/min, an alarm of AG Airway
Occluded is given. It indicates that there is no leakage.
The measurement accuracy of CO
2
, N
2
O, O
2
and AA (AA represents an
anesthetic agent) meets the product specifications in the Operator's
Manual.
EEG test (you can select either method to perform the test)
Method 1: The EEG wave is displayed on the monitor.
Method 2: All the leads are green then pass in the EEG module resistance
test.
Method 3: The resistance values displayed on the monitor are 1kΩ
BIS test (you can select either method to perform the test)
Method 1: The BIS value measured on healthy, wide-awake adult is
within 80-100.
To Next Page
