Output Conguration 42
The Single CH display will adjust to allow current conguration between .030 A to 16 A for model 9140
and .030 A to 8 A for model 9141.
Figure 4.13 Parallel CH 1+2 Single Channel Display
Protection Setting menu will also adjust the congurable range of each parameter.
Figure 4.14 Parallel CH 1+2 Protection Settings
