VC-6000
TM
Compact monitor Part C Sensor block
- 8 - C100583.002 Components Vers. 07 © VC-6000
TM
Compact monitor Sept. 2011
♦ <Sensitivity>
This parameter describes the sensor sensitivity (transmission factor) in
the correct physical unit for the connected sensor. The unit of sensitivity
(e.g. mV/g or V/m/s) is determined by the application firmware of the
VIBROCONTROL 6000 Compact monitor and cannot be changed at the
instrument. The numeric value of the sensitivity can be changed within
its setting range. The correct setting should be taken from the technical
documentation of the connected sensor.
Setting range for the sensitivity:
Sensitivity Minimum: -99999.99 Maximum: + 99999.99
Setting values for Brüel & Kjær Vibro sensors:
Sensor Sensitivity
AS-02x, AS-03x, AS-06x 100 mV/g
VS-068, VS-069 100 V/m/s (= mV/mm/s)
For further values consult the
sensor documentation
♦ <Input range>
This parameter defines the maximum input signal (peak value) in the AC
signal path that can be processed without over-ranging the signal path.
The unit of the <input range> corresponds to the physical unit of the
value measured in the application. The input signal must be integrated
if, for example, acceleration sensors are used to monitor vibration
speeds. The physical unit of the <input range> must in this event be
specified in mm/s. The <input range> is determined by the
VIBROCONTROL 6000 Compact monitor application firmware; it cannot
be changed later in the unit.
The physical unit of the input range (e.g. mm/s or g) is determined by
the application firmware of the VIBROCONTROL 6000 Compact monitor
and cannot be changed at the instrument.
The numeric value of the input range can be changed within its setting
range. The correct setting should be taken from the technical documen-
tation of the connected sensor.
Setting range of the input range:
Input range Minimum: 0 Maximum: + 99999.99
Maximum set-points for VS sensors:
Sensitivity Input range
100 mV/mm/s 120 mm/s
75 mV/mm/s 160 mm/s
70 mV/mm/s 170 mm/s
