VC-6000
TM
Compact monitor Part C Cyclic peak-peak measurement
- 48 - C100583.002 Components Vers. 07 © VC-6000
TM
Compact monitor Sept. 2011
15.2.2 Configuration parameters
♦ <Reset / Reset>
The Reset parameter deletes the currently saved MAX-HOLD value so
that a new maximum value can be saved. The parameter can be
activated via an OPC-server or a BINARY-IN.
Reset Yes No
15.2.3 Parameter summary
Parameter name Setup range adjustable
Max value Display only No
Unit m/s², g, in/s², mm/s²,
mm/s in/s, mm, µm, mils,
eu, 1, C, F, K, V, BCU,
R, s, mA, in, rpm, Hz,
cpm,
No
Reset Yes / No Yes
16 MIN-HOLD measurement
16.1 Function
♦ The MIN-HOLD measurement continuously acquires the minimum value
of a scalar value.
♦ The minimum value is continuously overwritten by a new lower value.
♦ The MIN-HOLD measurement is an optional signal path component.
The MIN-Hold block is arranged in the signal-flow chart directly after a
measurement value component.
♦ There are a number of ways to reset the MIN-HOLD block. The reset
can be carried out locally or remotely:
(i) Over a connected Binary-input
(ii) Over the OPC-server
(iii) Through a global Reset
♦ The current measured value in the block, including a time stamp of the
last archived value, can be read by a downstream OPC-server through
the Interface or Communication module.
