Highpass / Lowpass filter Part C VC-6000

Compact monitor

Compact monitor Sept.2011 C100583.002 Components Vers. 07 - 21 -

4.2.9 Variable highpass filter

♦ <Corner frequency > of the filter:

The corner frequency of the variable highpass filter is as a rule preset to

10 Hz. The settings in the instrument can be changed according to the

values shown in table 2. Filter settings that are sensible for the machine

being monitored are the responsibility of the user.

Corner frequency in Hz

100 1 k 10 k

1.25 12.5 125 1.25 k 12.5 k

1.6 16 160 1.6 k 16 k

2 20 200 2 k 20 k

2.5 25 250 2.5 k

3.15 31.5 315 3.15 k

4 40 400 4 k

5 50 500 5 k

6.3 63 630 6,3 k

8 80 800 8 k

Table 2: Corner frequencies for variable highpass filter
