♦ <Time out>
This parameter defines the maximum time interval between sequential
trigger events. If the time interval is greater than the defined time, the
measurement task is stopped (zero-speed criterion). The measurement
task is automatically started when a new trigger event no longer fulfils
the zero-speed criterion.
Minimum: 0.01 s Maximum: 8.00 s Step size: 0.01 s
Works pre-setting 0.5 s
Note:
The parameter can also be used to start the vector measurement only once
the steady-state operational condition has been reached.
♦ <Factor>
This parameter is used to select the harmonic that is to be measured,
i.e. Factor = 1 for vector 1n, Factor = 2 for vector 2n, etc.
Minimum: 1 Maximum: 999 Step size: 1
Works pre-setting 1
Note:
Vector measurement is limited to frequencies up to a maximum of 5 kHz.
This is to be noted when selecting the factor with a given rotational speed.
17.2.2 Summary of the parameters
Parameter name Value range changeable
Betrag / Magnitude Display: Current value No
Einheit / Unit m/s², g, in/s², mm/s², in/s, µm,
mils, eu, 1
No
Phase / Phase Display: Current value No
Signalbewertung
Signal detection
RMS, peak or peak-peak Yes
Max. Messzeit
Max. meas. time
0,1 s...99,99 s Yes
Bandbreite
Bandwidth
44%, 22%, 11%, 6%,3% or 1% Yes
Max. Impulsabst./
Time out
0,01 s...8,00 s Yes
Faktor / Multiplier 1...99 Yes
