BASE Module Part B VC-6000
TM
Compact monitor
© VC-6000
TM
Compact monitor Nov, 2014 C100584.002 Module Vers. 08 - 17 -
1.5.3 System
System function
Processor DSP Type 56309@ 98,304 MHz
Memory 16 Mbit Flash
Measurement and Monitoring function
A/D converter 6-channel with 14 bit resolution
Sampling frequency 64 kHz per channel
Signal processing all channels continuous
Internal cycle time 5 ms
Minimum reaction time 5 ms + measuring time
Specialities Hot-swap capability for module exchange
OK-relay
Maximum contact voltage < 50 V
Maximum current < 500 mA
Minimum current 10 µA
Minimum voltage 10 mV
Caution!
The maximum values must not be exceeded. Take precautions for inductive
or capacitive loads.
OK-LED Green = OK; OFF = System interruption
Note:
The OK-LED gives signals for various system conditions through a flashing
pattern. For a corresponding description consult section D, chapter 12.4.
