The signal-flow chart Part A VC 6000

Compact monitor

Compact monitor Juni 2014 C100575.002 Introduction Vers.10 - 7 -

5 The signal-flow chart

The signal-flow chart describes the functional construction of the monitoring

system.

Here all the measuring and monitoring tasks with their signal-flow

components are displayed. Each signal-flow component is characterised by

its properties and parameters. The entire functionality is a result of the

cooperative operation of the individual components.

The basic properties of a measuring and monitoring task are defined by the

instrument’s implemented firmware. These properties cannot be changed at

the instrument.

Parameter settings, (e.g. limit setpoints, relay switching mode, averaging

times, DC output characteristics, etc.) can be edited using the User-terminal.

These setting options are identified in parameter configuration sheet.

Each VIBROCONTROL 6000 Compact monitor has a valid signal-flow chart

and a valid parameter configuration sheet. In this signal-flow chart and the

parameter configuration sheet all existing available components in the

system, with their links, are displayed in an overview.

NOTE:

Please document all settings that are changed so the fastest possible

assistance can be provided in case of an error. The changes can be

documented in either a parameter setting sheet.

What information is evident in the signal-flow chart?

♦ The components on the left (red frame) are assigned for acquisition of

the input signals. These input components form the interfaces for the

sensors.

♦ Components on the right (yellow frame) are assigned the task of outputs

for events that occur. These form the interfaces to external, peripheral

electronic equipment.

♦ The signal-flow chart is to be used to identify in which functional

relationship the components are linked to one another.

♦ The type identification of the basic configuration, material number and

serial number are entered in the footline of the signal-flow chart. This

information must correspond with the information on the name plate of

the VIBROCONTROL 6000 Compact monitor !


