VC-6000
TM
Compact monitor Part C Monitor (Absolute) block
- 64 - C100583.002 Components Vers. 07 © VC-6000
TM
Compact monitor Sept. 2011
♦ <Trip Multiplier>
This parameter is for setting the value of the <Trip Multiplier> function,
which can be a component of a monitoring system. With <Trip Multiplier
ON> (only with automatic status identification!) the valid limit setpoint of
a Monitor Block is multiplied by the value of the <Trip Multiplier>. The
setting can be changed at the instrument.
The <Trip Multiplier> function should be used exclusively for a high limit
setpoint. It is principally sensible for vibration measurements and
permits a simple form of status-dependent machine monitoring. For
example the limit setpoint can be increased for a short time so that
during run-up of the machine, when there are anticipated resonance
regions, no false alarms will be signalled.
To put the <Trip Multiplier> function into operation the
VIBROCONTROL 6000 Compact monitor must be prepared in advance
for this function at our works. In the simplest case the switching on and
off is done through a binary status signal.
If the VIBROCONTROL 6000 Compact monitor is not equipped with this
<Trip Multiplier> function, the <Trip Multiplier> will not appear.
Minimum: 1.0 Maximum: + 999.9 Step size: 0.1
Works pre-setting 1.0
20.2.2 Summary of the parameters
Parameter name Value range changeable
Limit type Upper or lower limit Yes
Limit setpoint -99999.99...+ 99999.99 Yes
Hysteresis -99999.99...+ 99999.99 Yes
Time delay 0,00 s...99.99 s Yes
Acknowledge Yes or No Yes
Trip override Switch On or Off Yes
Trip multiplier 1.0...999.9 Yes
