3 Binary-input block
3.1 Function
♦ The Binary (input) block is an optional signal path component. It
contains all parameters necessary for exactly defining the properties of
one input channel of a BINARY-IN module.
♦ Through the parameters of the Binary-input block the input signal type,
active status and time delays can be defined.
♦ A BINARY-IN module has three input channels. Therefore three Binary-
input blocks are necessary to describe all channels of the module.
♦ A Binary-input block can provide status information for various
subsequent blocks, e.g. Monitor, Logic block etc.
3.2 Parameters and setting ranges
3.2.1 Parameter list
♦ <Socket no.>
This parameter provides information about the physical socket number
of the BINARY-IN module on the Base module. The settings are defined
by the application firmware of the VIBROCONTROL 6000 Compact
monitor and cannot be changed at the instrument.
Note:
The function of the Binary-IN module is guaranteed only when the physical
module configuration has not been changed !
Socket no. 1, 2, 3, 4, 5, 6, 7, 8 or 9
♦ <Channel no.>
This parameters informs you about the physical channel allocation of
the BINARY-IN module. The settings are defined by the application
firmware of the
VIBROCONTROL 6000 Compact monitor and cannot be
changed at the instrument.
Channel no. A or B or C
