Mounting and Installation Part A VC 6000
TM
Compact monitor
© VC 6000
TM
Compact monitor Juni 2014 C100575.002 Introduction Vers.10 - 35 -
♦ What happens after the start-up?
The VIBROCONTROL 6000 Compact monitor
is configured to
correspond to the require-ments of the application. When all the sensors
are correctly installed the monitoring task proceeds 10s after being
switched on.
In applications that contain at least one V-TIM the settling time amounts
to approx. 45 seconds. During this time all modules, i.e. all LEDs, relays
and current outputs, assume the condition they had at the last save
action.
If there is an error on the side of the sensors, this will be signalled by the
LEDs on the sensor modules and the relay modules and by the OK LED
(Please consult also chapter 8.3.3
).
♦ What to do in case of an error?
In case of an error we recommend that you connect the User-terminal
and check out the contents of the logbook.
9.6.2 Function testing
♦ How will I know that the VIBROCONTROL 6000 Compact monitor is
functioning correctly?
All LEDs will be green and the connected outputs will be signalling no
errors.
♦ What are the meanings of the LED signals at the sensor and relay
modules?
Please consult chapter 6.2.3
♦ Function testing with the User Terminal
We recommend that you check all the settings with the User Terminal
after the instrument start-up.
Connect the User Terminal to the VIBROCONTROL 6000 Compact
monito
r at the connection plug X24 (DSUB connection). The User
Terminal will login with a display of the Start screen, or the request for
entry of the CLOCK REFERENCE (date and time) will appear.
It is important that the CLOCK REFERENCE (date and time) be set up
so that future entries in the logbook can be correctly recorded.
When you carry out the CLOCK REFERENCE set-up consult section D
„Dialogue with the User-terminal“.
Then check out the parameter settings entered in the signal-flow chart.
♦ Are the parameter settings correct?
Now check the signal-flow chart for the parameter settings entered
there.
The VIBROCONTROL 6000 Compact monitor
is configured to
correspond with the require-ments of the application. As a rule the
sensor settings, processing criteria and limit setpoints will correspond to
the works pre-settings.
These works pre-settings must be adapted to the known monitoring task
(e.g. other sensor sensitivity, other limit setpoint settings.
These changes can be made with the User Terminal using the SUPER
USER password. (See section D: Dialogue with the User Terminal)
