Typical measurement tasks Part A VC 6000
TM
Compact monitor
© VC 6000
TM
Compact monitor Juni 2014 C100575.002 Introduction Vers.10 - 40 -
11.2.6 Process value
Input sensitivity 4 ... 20 mA corr. to 0 ... 150 eu
Measurement type Quasi-static process value (DC-value)
Measurement range 0 ... 150 eu
Averaging time 1 s
Measurement
accuracy
< 1 % of measured value plus 0,1 % of measurement range
full-scale value
11.2.7 Speed
Input sensitivity 1 mV/mV
Measurement type Shaft speed in [rpm]
Factor & Divisor Resp. 1 (corr. to 1 impulse per revolution)
Measurement time 0,5 s
Max. impulse interval 1 s
Measurement
accuracy
Approx. 0.01 % of measured value
11.2.8 Rod-drop
Input sensitivity
For displacement sensors 4 mV/µm
Measurement type Cycle DC-value of the geometrically corrected rod-drop
Measurement range 4 mm (without geometric correction)
Averaging time 50 cycles
Operating type Customer-specific (one position, two positions or averaged
cycle)
Measurement
position in the cycle
Customer-specific
Measurement
accuracy
< 0,75 % of measured value plus 1 % of measurement range
full-scale value
