3 Structure of this documentation
This documentation is divided into 5 sections:
Individual instrument documentation
B. Introduction to the VIBROCONTROL 6000 Compact monitor with the
objective toward commissioning
C. Technical data for the hardware
D. The signal-flow chart components and their parameters
E. User’s dialogue of the VIBROCONTROL 6000 Compact monitor
Where can I find which type of information?
 Commissioning:
When a prepared VIBROCONTROL 6000 Compact monitor is to be
taken into operation, it is generally sufficient to read individual
instrument documentation and section A.
 Technical data of the module:
When your interest is in special technical data, you will find it in
section B.
 Parameter settings:
When any parameters are to be edited the background information can
be found in section C.
 User Terminal dialogue description:
In section D the options for communicating with the VIBROCONTROL
6000 Compact monitor
via the User Terminal are described.
 Technical schedules:
In section “Individual instrument documentation” you will find the
individual instrument documents:
• Basic configuration description
• Signal-flow chart
• Configuration sheet
• Parameter setting sheet
Further information:
♦ You can find further language versions of the handbook on the CD which
accompanies thrhandbook.
♦ On the internet under www.bkvibro.com you can also find further
information about the VIBROCONTROL 6000 Compact monitor .
