Sensor-(A/B) block Part C VC-6000
TM
Compact monitor
© VC-6000
TM
Compact monitor Sept.2011 C100583.002 Components Vers. 07 - 11 -
2 Sensor-(A/B) block
2.1 Function
♦ The Sensor (A/B) block is the configuration interface for all 2-channel
input modules (e.g. GP-SIM) and the 2-channel BCU conditioning
module.
♦ The Sensor (A/B) block contains all parameters required for the
configuration of input channels.
♦ All settings directly associated with the input channels are in the Sensor
(A/B) block.
2.2 Parameters and setting ranges for GP-TIM
2.2.1 Parameter list
♦ <Socket no.>
This parameter informs you about the physical socket number of the
input module. The settings are determined by the application firmware of
the VIBROCONTROL 6000 Compact monitor and cannot be changed at
the instrument.
Note:
The measurement and monitoring function of an input channel is guaranteed
only when the physical module configuration is not changed!
Socket no. 1 / 2 / 3 No. of the socket position
on the Base module
♦ <Sensitivity A> and <Sensitivity B>
This parameter describes the sensitivity (transmission factor) in the
calibration unit of the incoming signal.
The unit of sensitivity (e.g. mV/eu or µA/eu) is determined by the
application firmware of the VIBROCONTROL 6000 Compact monitor
and cannot be changed at the instrument. The numeric value of the
sensitivity can be changed wthin the setting range.
The correct setting should be taken from technical documentation of the
input signal.
Setting range for the sensitivity:
Sensitivity A Minimum: -99999.99 Maximum: + 99999.99
Sensitivity B Minimum: -99999.99 Maximum: + 99999.99
