BK Vibro VIBROCONTROL 6000 - Technical Specifications and System Reliability; System Reliability and Standards Compliance

System reliability Part A VC 6000
TM
Compact monitor
© VC 6000
TM
Compact monitor Juni 2014 C100575.002 Introduction Vers.10 - 13 -
8 System reliability
8.1 Standards conformity
C-ticking confirms conformity with the EMV
requirements of the Australian Government
Agency (ACA)
Safety
EN 61010-1 “
CB Test Certificate
IEC 61010-1 : 2001
EMC
EN 61326-1 “
Temperature
DIN EN 60068-2-1 : 1995-03 Cold 20 °C Working
-40 °C Storage
DIN EN 60068-2-2 : 1994-08 Dry heat +70 °C Working
+85 °C Storage
Note:
If the VC-6000 Compact monitor is mounted in a protective housing
AC-2112, the following temperature ranges are recommended:
-30 °C… +40 °C ( ambient temperature).
Housing
EN 60529: Housing protection class (IP-Code): IP 20
Electrical and electronics law (ElektroG)
WEEE-Reg.-No.: DE 69572330
Product category / application area: 9

