1.5 Technical data
1.5.1 Electrical power supply
AC power supply
Input voltage range 90 ... 264 V AC
Frequency range 50 / 60 Hz
Maximum power consumption 40 VA
LED power supply monitor Green = OK, OFF = Interruption
Instrument fuses (F101, F102) T2A IEC 127
Size 5 x 20 mm
Note:
The PE-connection is attached to the instrument housing!
DC power supply
Input voltage range 20 ... 75 V DC
Maximum power consumption 40 VA
Instrument protection (F101) T2A IEC 60127
Type 5 x 20 mm
LED power supply monitor Green = OK; OFF = Interruption
Caution!
Maximally 75 V smoothed DC voltage may be attached!
Note:
The PE-connection can be attached at connection X28!
1.5.2 Mechanical execution
Socket positions
No. of socket positions (total) 9 (X1_M to X9_M)
No. of socket positions for input modules 3 (X1_M to X3_M)
No. of socket positions for output modules 6 (X4_M to X9_M)


