1.4.3.6 System interface: X25 – ESSI
This interface is reserved for future extensions.
1.4.3.7 System-interface: X26 and X27 – SCI-IN / SCI-OUT
SCI stands for Serial Communication Interface
These two connections allow, in combination with a suitable converter
(AC-5003), a serial communication to a PC (RS-232 interface) or a
connection to a TCP/IP network through a Gateway (AC-5004). This
communication is required, e.g. for a firmware download or to connect a
VIBROCONTROL 6000 Compact monitor with an OPC-server (OPC DA-
server – Type 7131).
Connection
X26
SCI IN (Serial communication interface)
Pin 1 OUT Wire back extension
Pin 2 RXD IN Receive data
Pin 3 0 VD OUT Ground
Pin 4 SCLK IN Clock In
Pin 5 5 VD OUT 5 V supply
Connection
X27
SCI OUT (Serial communication interface)
Pin 1 OUT Wire back extension
Pin 2 TXD OUT Transmit data
Pin 3 0 VD OUT Ground
Pin 4 LOAD OUT Low for boot from SCI
(download)
Note:
For more detailed information about the connection of the converter of the
Gateway and the OPC DA-server – Type 7131 please use the corres-
ponding product documentation.
