Cyclic peak-peak measurement Part C VC-6000
TM
Compact monitor
© VC-6000
TM
Compact monitor Sept.2011 C100583.002 Components Vers. 07 - 41 -
12.2.2 Configuration parameters
♦ <Rise time>
The parameter rise time corresponds to the charge time-constant of the
peak-peak measurement. The rise time can be adjusted within the setup
range.
Setup range for the time-constant of the rise time:
Minimum: 0 ms Maximum: 99 ms Increment size
1 ms
Works default setting 3 ms
Setup hint for the rise time:
A longer rise time evens out fast changes in the signal progress. The
resulting measured value will therefore be lower than with a shorter rise
time.
With a rise time of 0 ms the actual maximum rise in the signal progression
will be acquired as the peak-peak measurement value.
♦ <No. of averages>
The no. of averages parameter defines number of trigger cycles
necessary to be able to receive an averaged cyclic peak-peak value.
Setup range for no. of averages:
Minimum: 1 Maximum: 999 Increment size 1
Works default setting 1
♦ <Time out>
The time out parameter monitors the trigger signal. When no further
trigger signals are acquired during the defined time period the
measurement is stopped. When further trigger signals are received the
measurement is started once again.
Setup range:
Minimum:
0.1 s (= 10 Hz)
Maximum:
100.0 s = 0.01 Hz
Works default
setting
3.0 s
