System reliability Part A VC 6000
TM
Compact monitor
© VC 6000
TM
Compact monitor Juni 2014 C100575.002 Introduction Vers.10 - 15 -
8.2 Technical data
Housing
Protection class IP 20
Dimensions 311 x 170 x 113 mm (width x height x depth)
Weight, housing (empty) approx. 1,5 kg
Weight, base module approx. 450 g
Weight, plug-in module approx. 35 g
Material St 12 ZE 25/25, Surface powder-sprayed
Operating temperature range -20 °C to + 70 °C
1
Storage temperature range -40 °C to + 85 °C
Maximum humidity 95% non condensing
Mounting according to regulation, in a control
cabinet or protective housing!
Electrical power requirements
AC power supply
Input voltage range 90 ... 264 V AC
Frequency range 50 / 60 Hz
Maximum power consumption 40 VA
Power supply LED display Green = OK, OFF = Interruption
Instrument fuses (F101, F102) T2A IEC 127
size 5 x 20 mm
CAUTION!
The voltage supply may be connected only by isolating equipment (e.g.
a switch or circuit-breaker).
The device used an an isolator must fulfil the requirements of
IEC 60947-1 and IEC 60947-3 and be suitable for the application.
CAUTION HIGH VOLTAGE!
The housing cover of the VIBROCONTROL 6000 Compact monitor may be
removed only by technical personnel!!
1
Due to the principle conditions of heat development of the current outputs of the DC output modules,
a maximum of 3 DC output modules can be permitted at this ambient temperature.
