The configuration sheet Part A VC 6000
TM
Compact monitor
© VC 6000
TM
Compact monitor Juni 2014 C100575.002 Introduction Vers.10 - 12 -
Explanation of the example:
♦ In this example not all the available sockets are occupied. Depending on
the monitoring task, it is possible that not all or other module sockets will
be necessary in a particular case.
♦ The sensor modules are at sockets 1 and 3. In the example these are
respectively input modules for AS- sensors (CCS).
♦ The 2-channel relay output modules are at sockets 7 and 9.
♦ The 2-channel DC output modules for voltage/current outputs is located
at socket 8.
7.2 Plug to socket position arrangement (in the example):
Connection
plug
Physical socket
of the module
Module in example
configuration
Description on
housing cover
X1 X1_M A-TIM (CCS) 1
X2 X2_M Not used 2
X3 X3_M A-TIM (CCS). 3
X4 X4_M Not used 4
X5 X5_M Not used 5
X6 X6_M Not used 6
X7 X7_M RELAY-OUT (2-ch.) 7
X8 X8_M DC-OUT (2-ch.) 8
X9 X9_M RELAY-OUT (2-ch.) 9
7.3 Connection plug layout
The connection plug layout differs according to the input, respectively output
modules used. In the description of the Base module (section B – Modules
Technical data) all layout options are given.
