Mounting and Installation Part A VC 6000

Compact monitor

Compact monitor Juni 2014 C100575.002 Introduction Vers.10 - 31 -

9.5.3 System connections

9.5.3.1 AC power supply

Recommended cross-sectional area for the connecting cables: 1,5 mm²

9.5.3.2 DC power supply

Recommended cross-sectional area for the connecting cables: 1,5 mm²

Caution!

Maximally 75 V smoothed DC voltage may be attached
