Sensor block Part C VC-6000

Compact monitor

Compact monitor Sept.2011 C100583.002 Components Vers. 07 - 7 -

1 Sensor block

1.1 Function

♦ The Sensor block is the configuration interface for all 1-channel input

modules.

♦ The Sensor block contains all the parameters required for the

configuration of input channels.

♦ All settings that directly affect the input channels are carried out in the

Sensor block.

1.2 Parameters and setting ranges

1.2.1 Parameter list

♦ <Socket no.>

This parameter provides information about the physical socket number

of the 1-channel input module.

The settings are determined through the application firmware of the

VIBROCONTROL 6000 Compact monitor and cannot be changed at the

instrument.

Note:

The measurement and monitoring function of an input channel is guaranteed

only when the physical module configuration is not changed!

Socket no. 1 / 2 / 3 No. of the socket on the

Base module


