Mounting and Installation Part A VC 6000
TM
Compact monitor
© VC 6000
TM
Compact monitor Juni 2014 C100575.002 Introduction Vers.10 - 25 -
9.4 Mounting the instrument
9.4.1 Mounting on a rail according to DIN EN 50022
♦ The mounting of the VIBROCONTROL 6000 Compact monitor has to be
done according to the regulation in a control cabinet or protective
housing !
♦ Position the VIBROCONTROL 6000 Compact monitor on the rail and
push downward until the instrument clips onto the rail.
♦ Check that the VIBROCONTROL 6000 Compact monitor is securely
fixed to the rail!
9.4.2 Removing from a rail
♦ For removal from a rail you need an adequately large, flat screwdriver.
♦ First of all lever one side of the clip device downward using the
screwdriver.
Then loosen the housing of the VIBROCONTROL 6000 Compact
monitor from the rail on the same side by hand.
♦ Then lever the other side clip device downward using the screwdriver.
Now loosen this side of the housing from the rail.
♦ The VIBROCONTROL 6000 Compact monitor can now be removed.
9.5 Making the connections
The electrical connections to the VIBROCONTROL 6000 Compact monitor
may be carried out only by technical personnel!
It is important to observe the grounding instructions!
Depending on how the VIBROCONTROL 6000 Compact monitor
is built up
various connections will be made. See the corresponding configuration
sheet for the instrument to determine which modules are contained in the
VIBROCONTROL 6000 Compact monitor . (See also chapter 8
„Commissioning“).
