24 Relay block

24.1 Function

♦ The Relay block is a signal path component. As a configuration interface

it contains a number of parameters that are required for setting a

respective relay output. If a number of relays are available, each single

relay output is equipped through its individual Relay block.

♦ Each Relay block is used for setting all the important relay parameters,

especially the switching mode (normally energised or normally de-

energised) and latching or non-latching operation.

♦ As a rule a Relay block is directly controlled from a monitor block. If this

is not the case then the LED at the relay output module is used to signal

the monitoring status and relay status. Each relay output has two LEDs

for this purpose, one green LED and a dual-colour red-yellow LED.

An exact description of the LED signals can be found in chapter of

section A of the handbook.

♦ The relay output is switched to correspond with the set signalling

strategy and signal status of the preceding monitoring components (e.g.

Monitor block).

♦ Status display of the output of the monitor module by LEDs.

24.2 Parameters and their setting ranges

The parameters described in the following section can be displayed and,

when possible, changed using the User Terminal.

♦ <Socket no.>

This parameters provides information about the physical socket number

of the relay output module. The settings are determined by the

application firmware of the VIBROCONTROL 6000 Compact monitor

and cannot be changed at the instrument.

Note:

The signalling function of a relay output is guaranteed only as long as the

physical module configuration is not changed!

Socket position on the VIBROCONTROL

6000 1 Basic module

1, 2, 3,4, 5, 6, 7, 8 or 9


