Compact monitor Part C Relay block
- 80 - C100583.002 Components Vers. 07 © VC-6000
TM
Compact monitor Sept. 2011
♦ <Channel no.>
This parameter provides information about the physical channel layout
of the relay output on the associated Relay-output module.
The setting is defined by the application firmware of the
VIBROCONTROL 6000 Compact monitor and cannot be changed at the
instrument.
Possible channel numbers A or B
♦ <Reset>
This parameter is relevant only in a case where the relay is operated as
a <latching> relay. Then the parameter <Reset> reverses the latching
status of the relay after it has been activated by an event and can be
executed in the
VIBROCONTROL 6000 Compact monitor only by using the
User Terminal.
Reset Yes No
♦ <Normal position>
This parameter defines whether the relay will operate with a normally
energised or a normally de-energised switching mode. This setting can
be changed at the instrument.
Switch mode
Normal position
Normally energised Normally de-
energised
♦ <Latching>
This parameter defines whether the relay will operate as a latching on
non-latching relay. This setting can be changed at the instrument.
If this parameter is set with Yes, when an event occurs the relay will
remain latched until it is reset through the User Terminal or through the
global Reset.
Latching Yes No
♦ <Ready / Enable>
With this parameter a relay output can be taken completely out of
operation by the setting <disabled>. The relay contacts are then
effectively inactive and are unable to switch any signals. For regular
monitoring the relays should be set as <enabled>. This setting can be
changed at the instrument.
Ready / Enable enabled disabled
