Sensor-(A/B) block Part C VC-6000
TM
Compact monitor
© VC-6000
TM
Compact monitor Sept.2011 C100583.002 Components Vers. 07 - 13 -
2.2.2 Summary of the parameters for GP-TIM
Parameter name Value range changeable
Socket no. 1 to 3 No
Sensitivity -99999.99...+ 99999.99 Yes
OK high -15.0 V...+ 15.0 V bzw.
- 30.0 mA...+ 30.0 mA
Yes
OK low -15.0 V...+ 15.0 V bzw.
- 30.0 mA...+ 30.0 mA
Yes
OK latching Yes / No Yes
Hardware Id. 8 No
2.3 Parameters and setting ranges for BCU-CON
2.3.1 Parameter list
♦ <Socket no.>
This parameter informs you about the physical socket number of the
input module. The settings are determined by the application firmware of
the VIBROCONTROL 6000 Compact monitor and cannot be changed at
the instrument.
Note:
The measurement and monitoring function of an input channel is guaranteed
only when the physical module configuration is not changed!
Socket no. 1 / 2 / 3 No. of the socket position
on the Base module
♦ <Input range>
This parameter determines the measurement range, and as a result the
maximum BCU value, that can be processed by the BCU-CON. If the
acquired signal is larger than the set input range, a channel over-range
will be signalled.
Setting range of the input:
Input range Minimum: 10.0 BCU Maximum: + 200.0 BCU
