Compact monitor Part C Sensor-(A/B) block
- 12 - C100583.002 Components Vers. 07 © VC-6000
TM
Compact monitor Sept. 2011
♦ < OK-high A> and < OK-high B> (OK-window OK-LED)
This parameter defines the high limit value of the OK-window for
channel A and channel B. The OK-high limit is always an absolute
voltage value in the unit [V] or an absolute current value in the unit [mA].
The OK-high limit can be changed within this setting range. If the sensor
signal reaches an absolute voltage or absolute current value that is
higher than the OK-high limit, an OK-fault will be signalled.
Setting range for the OK upper limit:
OK high limit
For voltage signals (GP-TIM)
Minimum: -15,0 V Maximum: + 15,0 V
For current signals (GP-TIM)
Minimum: -30,0mA Maximum: + 30,0 mA
♦ < OK-low A> and < OK-low B> (OK-window OK-LED)
This parameter defines the low limit of the OK-window for channel A and
channel B. The OK-low value is always an absolute voltage value in the
unit [V] or an absolute current value in the unit [mA]. The OK-low limit
can be changed within this setting range. If the sensor signal reaches an
absolute voltage or absolute current value that is lower than the OK-low
limit (e.g. through a cable break), an OK-fault will be signalled.
OK low limit
For voltage signals (GP-TIM)
Minimum: -15,0 V Maximum: + 15,0 V
For current signals (GP-TIM)
Minimum: -30,0mA Maximum: + 30,0 mA
♦ <OK latching>
This parameter defines whether the OK LED will operate in a latching or
non-latching mode. The setting can be changed at the instrument.
Settings:
OK latching Yes No
♦ <Hardware Id>
This parameter informs you about the type of input module. The settings
are determined by the application firmware and cannot be changed at
the instrument.
Hardware-Id
Module
8
GP-SIM
