Vector measurement Part C VC-6000
TM
Compact monitor
© VC-6000
TM
Compact monitor Sept.2011 C100583.002 Components Vers. 07 - 51 -
♦ <Unit>
The parameter unit is in the preparation of the application firmware and
is regulated by a firmware download changeable.
Unit
m/s², g, in/s², mm/s², in/s, µm, mils, eu, 1
♦ <Phase>
The parameter phase displays the value of the phase of the vector.
Phase
Current value
Value range: -180° to 180°
♦ <Signal detection>
This parameter is a scaling factor for the measured vector magnitude
Signal detection
• RMS
• peak (corr. to
)
•
peak-peak (corr. to 2 x peak)
