VC-6000
TM
Compact monitor Part C Cyclic peak-peak measurement
- 58 - C100583.002 Components Vers. 07 © VC-6000
TM
Compact monitor Sept. 2011
♦ <Zero offset>
This parameter determines the zero point. The required value at the
zero point is added to the measured value and the result is the final
read value, i.e. the zero point that is set corresponds to the
measurement result when the input signal is 0 V. The zero point has the
same unit as the measured value.
Minimum: -9999.99 Maximum: + 9999.99 Step size: 0.01
Works pre-setting 0.00
Example:
Zero point for the 1st measurement = 0 mm
1st read value = -0,3 mm
Required read value = + 2,24 mm
New zero point = required read value – 1st read value
New zero point = + 2,24 mm – (-0,3 mm) = + 2,54 mm
♦ <Meas. position 1>
This parameter defines the measurement position 1 in relation to the
trigger point time. In the operating mode „Averaged cycle“ this
parameter is ignored.
Minimum: 0.00 Maximum: + 359.00 Step size: 0.01
Works pre-
setting
0.00
♦ <Meas. position 2>
This parameter defines the measurement point 2 in relation to the
trigger point time in the operating mode „Two positions“. In the other
operating modes this parameter is ignored.
Minimum: 0.00 Maximum: + 359.00 Step size: 0.01
Works pre-
setting
0.00
♦ <Time out>
This parameter determines the maximum time interval between
sequential trigger events. If the actual interval is greater than the defined
interval, the measurement task is stopped (zero-rpm criterion). The
measurement task is automatically started when a new trigger event no
longer fulfils the zero-rpm criterion.
Minimum: 0.1 s Maximum: + 100.0 s Step size: 0.1 s
Works pre-setting 0.5 s
