VC-6000
TM
Compact monitor Part CDual-Monitor (2 absolute limit values) function
- 68 - C100583.002 Components Vers. 07 © VC-6000
TM
Compact monitor Sept. 2011
♦ <Alert TM-value>
This parameter is the multiplication factor for the Alert alarm of the
<Trip Multiply> function, which, as the case may be, can be a
component of the monitoring system. With <Trip Multiply ON>
(automatic status-identification only by a binary input signal) the Alert
alarm value that has been set in the Monitor block is multiplied by the
the number entered here. This value can be changed at the instrument.
The <Trip Multiply> function should be used exclusively for the upper
limit type. This is predominantly sensible for use with vibration
measurements and permits a simple form of operating mode-dependent
machine monitoring. For example the limit value is increased for a short
time by this factor so that during run-up of a machine no alarms will be
raised at the anticipated traversing of resonance speeds.
To be able to put the <Trip Multiply> function into operation the
VIBROCONTROL 6000 Compact monitor must be prepared at the
works with the function. In the simplest case the switching of the
function on and off is achieved by means of a binary status signal.
If the VIBROCONTROL 6000 Compact monitor is not equipped with the
<Trip Multiply> function the parameter <Trip Multiply> will not be
displayed.
Minimum: 1.0 Maximum: + 999.9 Step size: 0.1
Works pre-setting 1.0
♦ <Danger TM-value>
This parameter is the multiplication factor for the Danger alarm of the
<Trip Multiply> function, which, as the case may be, can be a
component of the monitoring system. With <Trip Multiply ON>
(automatic status-identification only by a binary input signal) the Danger
alarm value that has been set in the Monitor block is multiplied by the
the number entered here. This value can be changed at the instrument.
Note:
See also the explana
tion under <A
lert TM
-value> !
Minimum: 1.0 Maximum: + 999.9 Step size: 0.1
Works pre-setting 1.0
