Compact monitor Setting of sensor sensitivity and input range
Part D
- 26 - C100585.002 Communication Vers. 03 © VC-6000
TM
Compact monitor Dec 09
9.3 Setting the sensor input range
Setting the sensor input range will be shown in the following example:
The input range of a connected sensor is to be set to the value 10 g peak
(peak value). The signal-flow chart shows that the acceleration sensor is
connected to the sensor module Sensor 03.
Block level
USER MENU
NEXT
DATE & TIME
NEXT
SYSTEM
NEXT
LOGBOOK
NEXT
SENSOR 01
NEXT (until the SENSOR 03 block
appears)
SENSOR 03
ENTER BUTTON
SENSOR 03
Socket no.
NEXT
SENSOR 03
Sensitivity
NEXT
SENSOR 03
Input range
ENTER BUTTON
Input range
+00005.00g
With NEXT select the digit position to
be changed.
Input range
+0000
5.00g
Changing the digit:
Push and hold SHIFT, then push
NEXT / PREVIOUS to change the digit.
Input range
+0001
5.00g
